Double Row 2.0 Pitch Right-Angle Plug H 6.35mm Female Pin Header Connector Plastic Brass Contact PCB

Highlight

1. Multi‑form customization: Straight pin / Right‑angle / SMT termination, custom plastic insulator height available
2. SMT‑ready: Optional pick‑and‑place cap for automatic pick‑and‑place equipment
3. Production‑oriented packaging: Tube & Tape & Reel (T&R) options for SMT assembly line
4. Flexible pin count: 2‑40 positions, double row
5. RoHS & UL94V‑0 compliant insulator material

Product Description

Mechanical Performance

Environment & Soldering

Compatibility & Cross‑Reference

Mechanically and electrically compatible with mainstream 2.0mm pitch double‑row female header series from international brands (Molex, JAE, Samtec equivalent series).

Engineer note: Verify pitch, pin dimension, insulator height, and footprint before BOM substitution. Not an original OEM part; function‑equivalent drop‑in alternative for most industrial & consumer projects.

Product Features

1. Double‑row 2.0mm pitch right‑angle structure, side‑exit routing to save PCB vertical space
2. Precision‑stamped brass contacts, stable contact force for low‑resistance signal transmission
3. High‑temperature UL94V‑0 plastic housing, anti‑flammable for harsh‑environment PCB assembly
4. Multiple mechanical options: straight/right-angle / SMT termination, custom insulator height
5. SMT pick‑and‑place cap optional, fits fully‑automatic placement machines
6. Multiple packaging choices to match prototype & mass‑production workflows

Product Advantage

• Custom‑flexible: No‑tooling minor modification for insulator height, pin length, and plating
• Production‑friendly: Tape & Reel output eliminates manual pre‑sorting for SMT lines
• Cost‑competitive alternative: Replace expensive imported brand parts without performance loss
• Consistent coplanarity: Strict QC for SMT version to reduce tombstone & bad‑soldering risk
• Short lead‑time for samples & small‑batch validation

Application

• Industrial control PCB, PLC peripheral interfaces
• IoT gateway, sensor module board‑to‑board connection
• Embedded systems, development board peripheral sockets
• Consumer electronics, smart home hardware
• Test & measurement equipment, display module interconnects

Packaging Method

1. Tube packaging: For prototype / low‑volume batch, manual insertion or semi‑auto assembly. Cannot feed directly to SMT pick‑and‑place machine.
2. Tape & Reel (T&R): EIA‑481 standard carrier tape, with optional pick‑and‑place cap. Directly usable for automatic SMT placement equipment for mass‑production lines

Please specify packaging requirement when placing inquiry.

Lead Time

• Sample order: 3 working days
• Mass production orders: 1‑3 weeks, subject to quantity & customization complexity

Factory Certification & Custom Service

• Certifications: ISO9001, RoHS compliance
• Sample Policy: Free samples supported, fast sample delivery
• MOQ: Standard part MOQ:1000 pcs; Customized parts subject to tooling requirements
• Custom service: Custom insulator height, pin length, plating, special pin count, special housing color
•


Engineer Selection Guide (Engineer Tips)

1. Confirm pitch =2.0 mm, double‑row, verify mating male header dimension
2. Select termination type: Right‑angle(PTH) / Straight(PTH) / SMT surface‑mount
3. Define insulator height if a non‑standard height is required
4. Plating selection: Tin for general‑purpose; Gold flash for high‑vibration / long‑life‑cycle device
5. Packaging decision:
   • Prototype/small batch → Tube
   • Mass‑production with SMT line → Tape & Reel + pick‑and‑place cap
6. Confirm PCB footprint matches selected termination style before PCB layout release

Reminder: Request our datasheet & PCB footprint file for final design validation.
