Y-Type Dual-Row Straight Female Header Connector 2.54mm for PCB Brass Material

Highlight

1. Rich custom options: Straight / Right‑angle / SMT termination; custom insulator plastic height available
2. Optional pick‑place vacuum Cap for auto‑SMT assembly
3. Supports Tape & Reel packing for high‑speed SMT production line
4. Y‑type brass contact for stable dual‑point electrical contact
5. RoHS & REACH compliant, multiple plating thicknesses configurable
6. Fast sample turn‑over, free sample support for engineering validation



Product Description

Mechanical Performance

Environment & Soldering

Compatibility & Cross‑Reference

Mechanically & electrically compatible as a drop‑in substitute against mainstream international series:

• Replace Molex, JAE, Amphenol‑ICC standard 2.54mm dual row female header footprint

Note: Verify exact pin‑out, insulator height & plating thickness before BOM substitution; we can adjust dimension to match your target part number.

Product Features

1. Y‑shape brass terminal delivers dual‑point contact, anti-loosening under vibration
2. Multiple termination forms: straight/right-angle / SMT, one‑source for your different PCB layouts
3. Custom insulator height solves board stacking clearance limitation
4. Optional vacuum cap enables direct pick‑and‑place for SMT machine
5. UL94V‑0 flame‑retardant plastic, stable for consumer & industrial environments
6. Configurable plating (gold/tin) balances cost and anti‑corrosion requirements

Product Advantage

🔹 No secondary mold cost for most height & pin‑count variants, lower NRE for small‑batch engineering projects
🔹 Tape & Reel / Tube dual packing options, ready for your automated assembly line without extra re‑packing cost
🔹 Strict in‑house QC: contact resistance, withstand voltage, salt‑spray test implemented per batch
🔹 Short lead‑time for standard parts; flexible ODM for special pin‑missing / locating‑peg version
🔹 Factory direct supply, stable delivery vs long lead‑time of overseas brand channels

Application

• Embedded mainboard, development board, GPIO interface
• Industrial control modules, sensor signal transmission
• Consumer electronics, smart home hardware
• Communication equipment, PCB‑to‑PCB internal connection
• Medical device auxiliary signal link (non‑high‑voltage)
• Automation prototype & mass‑production projects

Packaging Method

1. Tube Packing: Standard PVC tube, for manual assembly/prototype sampling; not suitable for SMT auto‑mounter
2. Tape & Reel: Embossed carrier tape + cover tape on reel, directly compatible with SMT pick‑and‑place machine, for high‑volume mass production.

Please specify packing requirement when placing order; vacuum cap is required together for reel‑pack SMT version.

Lead Time

• Samples: 3 working days for standard items
• Bulk production order: 1‑3 weeks (depends on pin‑count, plating & packing type; custom modified parts need extra time)

Factory Certification & Custom Service

• Certifications: ISO9001, RoHS, REACH
• Sample Policy: Support free samples / fast sample output (customer bears freight cost)
• MOQ: Standard parts low MOQ; custom mold case subject to mold evaluation
• Custom available: pin‑count, insulator height, termination style, plating thickness, locating post, missing pin, vacuum cap, packing mode
• Service: Datasheet, 2D drawing, 3D STEP file can be provided for your PCB library building

Engineer Selection Guide (Engineer Tips)

1. Confirm pitch: fixed 2.54 mm for this series
2. Confirm pin count: 2×02P ~2×40P
3. Mounting type:
   • Through‑hole straight: high mechanical strength, for wave‑soldering
   • Right‑angle: 90° horizontal board‑to‑board connection
   • SMT: reflow process, needs vacuum cap + Tape & Reel packing
4. Insulator height: select standard height or submit custom height requirement
5. Plating: Gold for vibration / harsh environment; Tin for general cost‑sensitive projects
6. Packing: Tube for lab/prototype; Tape & Reel for automatic SMT production
7. If cross‑referencing an international brand part number, send the original datasheet for our verification before order.
