SMT 1.27mm Box 10 Pin Female Header Connector Dual Side

SMT 1.27mm Box 10 Pin Female Header Connector Dual Side
SMT 1.27mm Box 10 Pin Female Header Connector Dual Side
SMT 1.27mm Box 10 Pin Female Header Connector Dual Side SMT 1.27mm Box 10 Pin Female Header Connector Dual Side SMT 1.27mm Box 10 Pin Female Header Connector Dual Side

Large Image :  SMT 1.27mm Box 10 Pin Female Header Connector Dual Side

Product Details:
Place of Origin: Guangdong,China
Brand Name: XTK
Certification: CE/ROHS
Model Number: Box header connector
Payment & Shipping Terms:
Minimum Order Quantity: 500pcs
Packaging Details: inner package:in reel; Outer Package: reel in Carton
Delivery Time: 5-7 days
Payment Terms: L/C, T/T,Payyal
Supply Ability: 2KK pcs

SMT 1.27mm Box 10 Pin Female Header Connector Dual Side

Description
Pitch: 1.27mm Mounting  Type: SMT
No. Of Positions: 2-50p Durability Cycles : 5000 Cycles Min
Housing: Polyester(UL94V-0) Contact: Phosphor Bronze
High Light:

1.27mm Female Header Connector

,

SMT Female Header Connector

,

1.27 mm box header

.1.27mm dual side female header box header connector





Custom Headers provide design flexibility, production efficiency while decreasing needed equipment assets.with Horizontal, right-angle and vertical about orientation & single and dual Rows.



A box header connector is a male connector with exposed pins encompassed by side dividers which are molded onto a plastic base. Box headers are manufactured with a minimum of two pins in either single or double rows. They are widely used for board-to-board or wire-to-board connections.

Description

Pitch 1.27mm
Mounting Type SMT
No. Of Positions 2-50p
Rated current 1.0A AC
Rated voltage 50V AC/DC
Contact Resistance 20m ohms MAX
Insulation Resistance 1000m ohms min
Insertion Force 20gf/pin Min
Operation Temperature -40℃ to +105℃
Withstanding Voltage 500V/1min AC
Housing Polyester(UL94V-0)
Contact Phosphor bronze
Gender Female
Price Term FOB
Durability cycles 5000 Cycles Min
Lead Time 7-10 working Days

SMT 1.27mm Box 10 Pin Female Header Connector Dual Side 0



Feature

1. Box Header Connectors are available with through hole terminations in straight, right angle and SMT shape, with or without alignment posts.
2. Environmental friendly and ROHS compliant.
3. It’s cost-effective and convenient to transport.
4. Box Header Connectors are widely used in PCB circuit boards in electronics, electrical appliances etc.
5. A box header is easy to customize.
6. High and low-temperature resistance
Can withstand changes in a temperature difference of 145℃.



Application
Box header is widely used in displays, digital camera, MP3, MP4, PDA, computer, computer motherboard, a variety of mobile storage disk, card reader, security products, electricity meter, wireless telephone, mobile phone, interphone, program-controlled switches, VCD, DVD, LCM/LED display module, electronic toys, household appliances etc. As the most reliable connection plate to plate, wire to board provides.



OEM/ODM Producing

CNJWY has our own assembly lines from electroplating,stamping,moulding,injection and packaging.



Quality Guarantee

Strictly following the demands of ISO9001-2015,CNJWY is able to produce products of highest quality.



Competitive Price

More than 10 years of producing experience,CNJWY is always specializing in improving the production capacity.Competitiveness provides competitive price for the valued customers.



Our advantage

1) Technical support - both before and after sales, having outstanding professionals from like Dinkle, Anytek etc.
2) OEM/ODM - Precise mold design&development is our core competence. we service companies like Philips,Eby, Blockmaster etc.
3) Automation - Introduced latest automatic machines for assembly lines, cut the cost down and keep the quality steady more.
4) ERP - Introduced ERP management system in 2013, which assure us to bring faster response and better service to our clients.
5) One-stop solution – We manufacture terminal block,connector and enclosure. besides we have a trading company as our another professional team which can help our clients to outsource high cost-effective electronical products in china.



FAQ

Q1. what kind of products are you provide?
we are providing competitive solutions and diversified connectors and wire harness.


Q2. What is your MOQ?
MOQ is 500pcs, the quantity depend on the items you need.



Q3. What is your sample policy?
We can provide free samples, but customers need bear the courier cost.


Q4. How about your lead time?
it will take 3~5 days for the samples, mass production will take 2~3weeks, it depends
on the items and the quantity which your order. If you need items urgently, we will try to meet your lead time.


Q5. How about your terms of payment?
T/T in Advance or before shipment, Payment can negotiated when we have stable relationship.



Q6. What is your terms of delivery?
EXW, FOB, CFR, CIF, DDU.



Q7. Can you produce according to the samples or drawings?
Yes, we can produce via your samples or technical drawings. We can build the molds and jig. 3D file will provide to you confirm before produce.



Q8. how can you guarantee the products quality?
A: We has stick policy on the producing process, all products will 100% test before delivery.



Q9. How can I get quote?
A: It is helpful for us if you can provide the product details, detail description, photo or drawing. We will sent out alternative drawing when quote to you.


Q10. How do you make our business long-term and good relationship?
High quality, Rich experienced, Excellent service, will provide products with good quality and competitive price; Honesty and respect every customer as our friend.
