2.54mm Pitch 2*8 Pin IP68 Waterproof 3.0 A 120 V Female Header Connectors for PCB and BNC Antenna Connector

Highlight

1. Dual locking structure optional: ZIF / Non‑ZIF locking mechanism, stable retention force, avoids intermittent signals under continuous vibration and shock
2. Ultra‑thin mated height: Low profile design, saves vertical PCB stacking space for compact enclosure layout
3. Validated anti‑vibration performance: Passes strict vibration test, maintains stable contact for moving & outdoor equipment
4. IP68 fully sealed: Dust‑tight & waterproof when mated, resists liquid splash, immersion, and humidity erosion
5. 3.0A per pin / 120V rating: Support mixed signal & low‑power current transmission
6. Compatible with BNC antenna connector: Realize antenna‑PCB sealed integration

Product Description

Mechanical Performance

Environment & Soldering

Cross‑Reference / Compatible Replacement for International Brands

This 2.54mm 2*8P IP68 female header serves as a functional alternative for series from Molex, TE Connectivity, and Amphenol ICC standard 2.54mm header product lines.

Note: Please verify footprint, locking style, plating spec and IP requirement before direct drop‑in replacement. We support pin‑to‑pin customized modification to match original reference part number.

Product Features

• 2.54mm 2 rows ×8 positions female header, IP68 waterproof in mated state
• Optional ZIF / Non‑ZIF locking mechanism for anti‑disconnection
• Ultra‑thin mated height for space‑limited cabinet integration
• Validated anti‑vibration performance for dynamic working conditions
• Rated 3.0A 120V, support signal & small power circuit
• Dedicated mating with BNC antenna connector for sealed antenna‑PCB interconnection
• RoHS REACH compliant; multiple plating options available
• Support Tube / Reel tape‑and‑reel packing for automated assembly

Product Advantage

1. Sealed 2.54 standard pitch: Combine classic 2.54mm footprint with IP68 waterproof, no need to redesign the whole PCB for a harsh‑environment upgrade.
2. Selectable ZIF / Non‑ZIF lock: Non‑ZIF for low‑cost mass production; ZIF for frequent‑maintenance module swap.
3. Anti‑vibration optimized contact beam: Prevents signal dropout for moving devices, field‑proven for antenna connection.
4. Ultra‑low mated height: Solves space conflict in compact chassis, benefiting miniaturized equipment design.
5. Dual‑scenario adaptation: Works for general PCB board‑to‑board connection and direct BNC antenna connector mating.
6. Flexible packaging options: Tube or Tape‑and‑Reel for automatic SMT pick‑and‑place assembly line, eliminating manual‑placement cost.
7. Cost‑effective drop‑in replacement for international brands, short lead‑time for sample & bulk order.

Application

• Outdoor industrial control equipment
• BNC antenna module & wireless communication devices
• Marine / Off‑shore electronics
• Surveillance & outdoor monitoring hardware
• Vibration‑prone transportation‑mount electronics
• Harsh‑environment sensor modules
• Sealed IoT & outdoor smart devices

Packaging Method

1. Tube Packing: For prototypes, small‑batch or manual assembly. Easy component handling for lab evaluation.
2. Tape‑and‑Reel (Reel): For mass‑production, directly compatible with customer automatic SMT pick‑and‑place machine, no secondary manual operation required.

Please specify packaging requirement when placing PO.

Lead Time

• Sample order: 3 working days
• Bulk production order: 1‑3 weeks depending on order quantity
