5557 Automotive Double Row MX3.0MM Pitch Vertical Connector 43045 4P-24P Wire To Connector
Product Highlights
- Dual-row 3.0 mm pitch vertical header, 4P~24P full range for automotive, industrial & home appliances
- Housing: UL94V-0 flame retardant, anti-ignition for high-reliability power/signal connection
- Complete supporting terminals & wire harness processing service, one-stop sourcing
- Polarized design to avoid mis-mating; isolated contacts prevent short circuits
- RoHS & REACH compliant, low halogen option available
Technical Specifications
| Item |
Parameter |
| Electrical Performance |
|
| Rated Current |
Max 8.5A per pin |
| Rated Voltage |
600V AC/DC |
| Contact Resistance |
< 20 mΩ max after mating cycles |
| Insulation Resistance |
≥1000MΩ |
| Withstand Voltage |
AC 1500V, 1min no breakdown |
| Mechanical Performance |
|
| Mating Cycles |
≥30 cycles |
| Vibration / Shock |
Compliant with EIA-364, no discontinuity |
| Terminal Retention |
Anti-backout structure |
| Material & Plating |
|
| Housing |
PA66, UL94V-0 Black |
| Contact Material |
Brass Alloy |
| Plating |
Tin plating / Gold plating optional |
| Environmental & Soldering Guide |
|
| Operating Temp |
-40℃ ~ +105℃ |
| Reflow Soldering |
Peak temp 260℃, compatible with SMT reflow |
| Certifications |
RoHS, REACH, UL certified |
Cross Reference / Alternative Replacement
Direct drop-in replacement for Molex Micro-Fit 3.0 43045 series. Widely used as a substitute for JST, AMP / TE equivalent 3.0mm dual-row vertical wire-to-board connectors.
Same footprint & pinout, so most projects need no PCB redesign and save qualification costs.
Product Advantages
- Fully compatible pin layout, direct replacement of international big brands, shortens project validation cycle
- UL94V-0 flame-retardant plastic, stable performance for automotive & industrial high-temperature environments
- Reel tape packaging, ready for automatic SMT placement line
- One-stop service: supply housing + terminals + custom wire harness assembly
- Strict in-line inspection, stable contact resistance, anti-vibration for harsh working conditions
- Flexible pin count: 4P up to 24P, support power & mixed signal design
Application
- Automotive electronics: automotive control modules, vehicle sensors, car lighting
- Industrial equipment: PLC, power supply, servo drives, industrial controllers
- Home appliances: inverter, HVAC, smart kitchen appliances
- Power & energy storage modules, medical equipment, communication power units
Lead Time
- Samples: 3 working days
- Mass order: 1–2 weeks
Factory Certificate & Custom Service
- Certificates: UL, RoHS, REACH, ISO9001
- MOQ: Low MOQ available
- Sample Policy: Free samples supported, fast sample delivery
- Customization available: special plating, custom harness assembly, custom pin length, logo marking.
Customer Selection Guide
- Confirm pin count: select 4P~24P according to your signal/power circuit requirement
- Select contact plating: Tin for general power; Gold plating for low signal / high vibration application
- Check working temperature & flame resistance: UL94V-0 is mandatory for automotive/high-power appliances
- Packaging selection: choose reel if using automatic SMT line
- Wire gauge match: match crimp terminal with your wire AWG before harness assembly
- Recommend prototype test with our free samples before mass BOM lock
