Vertical 2.0mm Pitch Wafer PCB Connectors Wire To Board 180 Degree

Vertical Type 2.0mm Pitch PCB Housing Wafer Terminal Wire To Board 180 Degree

Product Description

Drawing

Feature

Ideal for compact applications, the 2.00mm Wire-to-Board Connector System provides electrical and mechanical reliability in a high-temperature design that meets a diverse range of industry requirements.

In microminiature wire-to-board applications, sometimes operators fail to ensure proper mating orientation, which can lead to end-product failure. The polarized ribs of the wafer Wire-to-Board Connector System prevent mismating and provide mating guidance. Often medical, automotive and home appliance designers have a real-estate space issue on their PC board because of increasing components.wafer Wire-to-Board Connector System features positive lock in a compact 2.00mm pitch design.
