4.5H 0.5mm Pitch FPC FFC Cable PCB Connectors S/T Connector For Flat Cable

Product Highlights

• 0.5 mm fine pitch, 4.5 mm vertical mounting height, S/T ZIF flip‑lock structure, vertical SMT for FPC / FFC flat cable
• Supports multi‑pin range, tape‑and‑reel for high‑speed SMT mass production
• LCP UL94V‑0 housing, phosphor bronze terminals, selective gold flash contact plating for stable signal transmission
• Top‑contact / Bottom‑contact optional, compatible with standard 0.3 mm thickness FPC & FFC ribbon cables
• RoHS & Halogen‑free compliant, cost‑effective alternative to imported brand equivalents

.

Full Technical Specifications

General Mechanical Specifications

Material & Electrical Characteristics

Environmental & Soldering Guidelines

Product Advantage

1. Structure Balance: 4.5 mm height delivers better cable holding force vs ultra‑low‑profile counterparts, reduces risk of cable drop‑out in vibration‑prone equipment
2. Design Flexibility: S/T flip‑lock + top/bottom contact options, support multiple FPC / FFC routing schemes, shorten customer mechanical design cycle
3. Mass‑production Friendly: Tape‑and‑reel packing, LCP high‑heat‑resistance housing, fully compatible with standard lead‑free SMT assembly lines
4. Cost‑competitive drop‑in replacement: Pin‑to‑pin compatible with mainstream imported series, lower total BOM cost without sacrificing reliability
5. Stable signal performance: Gold‑flash contact surface controls contact resistance drift, fit for LVDS, MIPI DSI and general signal transmission
