Short Overview: 4.2mm pitch 5557/5569 double-row straight pin ATX power connector, LCP high-temp housing, UL94V-0, halogen-free. Anti-unmating buckle design for heavy-vibration industrial & automotive applications. Complete housing & terminal set available.
Product Highlights
✅ Flame Resistance & Eco Material: Housing LCP, UL94V-0 flame rating, Halogen-Free, meets industrial & home appliance environmental requirements
✅ Anti-Vibration Anti-Unmating Double Buckle: Reinforced double-row locking buckle, prevents accidental disconnection under continuous shock & vibration in industrial / vehicle harsh environments
✅ Full Matching Components: Complete set including plastic housing (shell) + crimp terminals, one-stop procurement
✅ High Temperature LCP Material: Stable performance during SMT soldering, withstands high working ambient temperatures
Technical Specifications
| Item |
Details |
| Pitch |
4.2 mm |
| Structure |
Double row, straight pin, buckle locking |
| Model |
5557 / 5569 series |
| Electrical Performance |
| Rated Current |
9A per circuit |
| Rated Voltage |
250V AC |
| Contact Resistance |
≤20mΩ |
| Insulation Resistance |
≥1000MΩ |
| Withstand Voltage |
1500V AC for 1min |
| Mechanical Performance |
| Insertion / Withdrawal Cycles |
≥1000 times |
| Locking Force |
Reinforced double buckle, anti-unmating under vibration |
| Contact Retention Force |
Meets IEC vibration & shock test standard |
| Material, Plating & Environment |
| Housing Material |
High-temperature LCP |
| Flame Class |
UL94V-0, Halogen-Free |
| Terminal Base Material |
Copper alloy |
| Plating |
Tin plating (gold plating optional) |
| Operating Temp |
-40℃ ~ +125℃ |
| Soldering Guide |
SMT soldering compatible; Reflow peak temp ≤260℃, max 10s |
Cross Reference / Alternative Replacement
Direct drop-in compatible replacement for internationally famous brands:
- JST: 5557 / 5569 series
- Molex: 3901 series
- TE (AMP): 4.2mm pitch ATX power series connectors
Note: Pin count needs to match when cross using.
Product Features
- 4.2mm standard pitch, double row straight pin layout, classic ATX power supply socket design
- Double buckle locking mechanism, avoids accidental unmating under vibration
- LCP high-temp plastic, stable at high temperatures in soldering & working environments
- UL94V-0 flame retardant, halogen-free, eco-compliant
- Complete housing + terminal solution, easy assembly
Product Advantages
- Anti-drop locking design: Solves the customer pain point of connector loosening & disconnection under vibration for industrial & on-board equipment
- High-temperature-resistant LCP, no deformation during reflow soldering
- Strict material control: UL94V-0 + Halogen-Free, satisfies safety audit for industrial, home appliance & partial automotive projects
- Pin-to-pin compatible with JST / Molex / TE, convenient BOM substitution without PCB redesign
- Factory-direct supply; supports custom pin count, plating & packaging
Application
- ATX PC power supply
- Industrial control equipment, servo power port
- Home appliances (air conditioner, inverter)
- Automotive auxiliary power modules
- Medical power equipment
- LED power driver & battery pack
Packaging Method
- Standard: Anti-static bag packing
- Optional: White / Neutral carton box packing. Custom packing label & barcodes available upon request.
Payment Method
EXW, FOB, CIF, CPT, T/T, L/C available
Lead Time
- Samples: 3 working days
- Mass order: 1–2 weeks
Factory Certificate & Custom Service
- Certifications: UL, RoHS, REACH, ISO9001
- MOQ: Low MOQ for standard items
- Sample Policy: Free samples available / Fast sample delivery. Custom service: Custom pin count, plating thickness, cable harness assembly, special packaging & marking.
Customer Selection Guide
- Confirm pin count before cross-reference replacement to match footprint
- For high vibration scenarios, choose double buckle locking version to prevent unmating
- For soldering process: confirm reflow temperature ≤260℃
- For automotive projects, request full material report & halogen certificate
- If gold plating is required, notify sales at the quotation stage
