2.5mm Pitch Battery Connector Female Gold-plated 4P

Highlight

Compact 2.5 mm pitch 4‑position SMT battery female socket, gold‑plated phosphor‑bronze contacts, low contact resistance, anti‑oxidation, up to 5000 mating cycles. Optimized for lithium‑ion battery modules delivering power + temperature/signal sensing on compact PCB space. RoHS‑compliant, supports standard SMT reflow assembly, available for OEM/ODM customization.

Product Description

Material & Electrical Characteristics

Environment & Soldering Guide

Product Features

• 2.5 mm center‑to‑center pitch, 4‑pin female receptacle, SMT PCB mounting
• Phosphor‑bronze spring contacts with gold plating: low contact resistance, anti‑corrosion & anti‑oxidation
• Spring‑beam contact structure: stable contact force, resists vibration & shock
• UL94‑V0 flame‑retardant insulator, excellent reflow soldering heat resistance
• Up to 5000 mating cycles for frequent plug‑unplug scenarios
• RoHS compliant; customizable pin height, gold‑plating thickness & polarization key option
• Space‑saving footprint, well‑suited for compact battery pack PCB layout

Product Advantage

1. Gold‑plated contact reliability: Avoid oxidation drift; contact resistance remains stable even after thousands of insertions, reducing power loss & hot‑spot risk vs tin‑plated alternatives.
2. Optimized spring‑beam geometry: Consistent spring pressure against battery male terminal; good anti‑vibration performance for portable & moving equipment, no intermittent power drop.
3. Manufacturing‑friendly: Strict dimensional consistency for high‑volume SMT mass production; low defective soldering rate.
4. Design flexibility: Support modification on contact height, gold thickness, and add polarization key; quick sample turnaround for project validation.
5. Cost‑competitive: Factory direct supply, equivalent performance to famous brand counterparts with better total cost of ownership for mass‑volume orders.

Application

• Portable consumer electronics: handheld terminals, POS equipment, scanners
• Lithium‑ion battery packs: multi‑cell battery modules with temperature‑sense signal
• Smart home hardware: smart locks, portable medical devices
• Industrial portable instruments, data loggers
• Robot auxiliary power, drone peripheral battery units
• Wearable & small battery‑powered IoT devices

Customization Options

1. Pin count logic: 4P for simultaneous power delivery + battery temperature/balance signal; select 2P only for pure power without sensing signal.
2. Gold‑plating option: Choose gold‑plated version if device works in humid / salt‑spray environment or requires frequent mating; tin‑plated alternative available for cost‑sensitive static‑connect projects.
3. PCB layout note: Reserve enough keep‑out space around connector housing; strictly follow our recommended reflow temperature curve to prevent plastic deformation.
4. Mating pair check: Verify male battery contact dimension, height, and pitch before finalizing design; mixed‑brand mating may cause incomplete engagement.
5. Current derating: Derate 30 % current under high‑temperature (> 60 ℃) working environment for long‑term reliability.
