DIP 2.54mm Pitch 26 Pin Header Connector Straight IDC Female Connector

DIP 2.54mm Pitch 26 Pin Header Connector Straight IDC Female Connector
DIP 2.54mm Pitch 26 Pin Header Connector Straight IDC Female Connector
DIP 2.54mm Pitch 26 Pin Header Connector Straight IDC Female Connector DIP 2.54mm Pitch 26 Pin Header Connector Straight IDC Female Connector DIP 2.54mm Pitch 26 Pin Header Connector Straight IDC Female Connector DIP 2.54mm Pitch 26 Pin Header Connector Straight IDC Female Connector

Large Image :  DIP 2.54mm Pitch 26 Pin Header Connector Straight IDC Female Connector

Product Details:
Place of Origin: Guangdong,China
Brand Name: XTKCONN
Certification: CE,SGS,ROHS,ISO9001
Model Number: Box header
Payment & Shipping Terms:
Minimum Order Quantity: 600pcs
Price: Negotiable price
Packaging Details: inner package:in bag; Outer Package: reel in Carton
Delivery Time: 5-7 days
Payment Terms: L/C, T/T,Payyal
Supply Ability: 3KK pcs

DIP 2.54mm Pitch 26 Pin Header Connector Straight IDC Female Connector

Description
Pitch: 2.54mm Insulation Resistance: 1000MOhm
Pin: 6-64pin Application: PCB
Material: PA6T/PA9T/LCP Rated Voltage: 1000V
High Light:

IDC 26 pin header connector

,

2.54mm 26 pin header connector

,

2.54mm IDC Female Connector

DIP 2.54mm Pitch 26 pin Box Header Straight Idc Female Connector





Product Description



Description 2.54mm box header H8.8 connector
Standard Dimension PA PB W Length

Custom Dimension
Pin ways 06~64P
Alternative Plating G/F Tin Sel. Gold/Tin
GO SN S0
Packing way PE Bag /Tube/ Tray/ Plastic box/ Tape&Reel Packing.
MOQ 500PCS
Delivery time 1-2weeks after confirm order

Engineering Specifications Rated Current:3.0AMP
Contact Resistance: 20mΩ Max
Withstand Voltage:1000V AC/DC
Insulation Resistance:1000MΩ Min
Operation Temperature: -40°c to +105°c
Contact Material :brass
Contact Plating: Au Over Ni
Insulator Material :Polyester (UL94V-0)
Standard: PA6T
Max.Processing Temp230°c for 30-60 Seconds / (260°c for 10 Seconds)





Product features



high temperature resistant to high voltage electrical conductivity.

Its function is to act as a bridge between the blocked or isolated circuits, and to take on the task of current or signal transmission.



Application



Mainly suitable for data communication and electronic equipment and welding on the PCB board, connected to the corresponding specification of IDC ribbon cable and the other circuit designers need to circuit. And if current usually transmission control signal.
