Name: Right Angle 12 pin FPC connector
Brand: Shenzhen Xietaikang Precision Electronic Co., Ltd.
SKU: FPC**-T1S1-2020-A
Price: 4.01 USD
Availability: InStock

Home > Products > FFC FPC Connector >

Right Angle 12 pin FPC connector

0.5mm 12 Pin FPC Connector

Right Angle 12 Pin FPC Connector

Right Angle 0.5 mm fpc connector

Place of Origin:

Guangdong,China

Brand Name:

XTKCONN

Certification:

CE,SGS,ROHS,ISO9001

Model Number:

FPC**-T1S1-2020-A

Request A Quote

Product Details

Pitch:

0.5mm

Pins:

4pin-68pin

Working Frequency:

Low Frequency

Craftsmanship:

Injection Molding

Gender:

Female

Interface Type::

ZIF

Highlight:

0.5mm 12 Pin FPC Connector

Right Angle 12 Pin FPC Connector

Right Angle 0.5 mm fpc connector

Payment & Shipping Terms

Minimum Order Quantity

500pcs

Price

Negotiable price

Packaging Details

vacuum package,boxes in carton

Delivery Time

5-7 days

Payment Terms

L/C,T/T,Payyal

Supply Ability

4KK pcs

0.5mm Pitch Butterfly Lock FFC/FPCH Connector Horizontal Lower Connection with 2.55H Height Flip Cover for Flat Flex Electronics

Get Best Price

Gold-plated 0.5mm Pitch FPCFFC Connector 2.7H Post-Pressure Horizontal SMD 10-68Pin 50V 0.5A

Get Best Price

0.5mm Pitch Vertical Unlocked SMD Misalignment Pin FPC Flat Wire Socket FFC/FFC Connector for Flat Flex Unlocking Flex Connector

Get Best Price

0.5mm Pitch 60PIN Vertical Positive Foot 5.2H Clamshell Buckle Flat Connector Cable Socket FPC FFC Cable PCB Connectors

Get Best Price

86 13711847246

tinaliao@xtkconnector.com

86-769-85150486

Contact Now

Product Description

Top/Bottom contact 0.50mm pitch FFC FPC Connector Surface Mount Right Angle 4~128 Position

Xietaikang`s FFC(Flexible Flat Cable) / FPC(Flexible Printed Circuit) connectors with wide variety of product line-up offer the best combination of signal reliability, compactness, wide circuit size range and cable style choices of any similar version in the market.

Description

Part Status	Active
Flat Flex Type	FFC, FPC
Mounting Type	Surface Mount, Right Angle
Connector/Contact Type	Contacts, Bottom
Number of Positions	4-68pin
Pitch	0.020" (0.50mm)
Termination	Solder
FFC, FCB Thickness	0.30mm
Height Above Board	0.075" (1.90mm)
Locking Feature	Flip Lock
Cable End Type	Tabbed, Tapered
Contact Material	Phosphor Bronze
Contact Finish	Gold
Housing Material	Liquid Crystal Poly mer (LCP), Glass Filled
Actuator Material	Polya mide (PA), Nylon, Glass Filled
Features	Solder Retention, Zero Insertion Force (ZIF)
Voltage Rating	50V
Operating Temperature	-40°C ~ 105°C
Material Flammability Rating	UL94 V-0
Current Rating (Amps)	0.5A
Contact Finish Thickness	1.97µin (0.050µm)
Housing Color	Beige
Actuator Color	Black
Mating Cycles	25

Right Angle 12 pin FPC connector

Shipping & Delivery item

1, We can shipping all over the world by DHL, UPS, FEdex, TNT and EMS. The packaging is very safe and strong. Please nitfy me you have any special needs

2, It will take around 3-5 days to reach your hands.

Product Type & condition

Because of the fluctuant sales situation. the stock parts are always changing and the stock list cannot be promptly updated. So please consult the stock situation when you inquire.

Warranty & Guarantee:

All components we sell the quality with 30 days Return policy from the day of shipment.

FAQ

1. Q: Do you have a catalogue? Can you send me the catalogue to check all your products?

A: Yes, you can contact us online or send an Email to get the catalogue.

2. Q: I can't find the product on your catalogue; can you make this product for me?

A: Our catalogue shows most of our products, but not all. Just let us know what product you need, and how many you want. If we do not have it, we can also design and make a new mould to produce it. For your reference, making an ordinary mould will take about35-45 days.

3. Q: Can you provide a sample? Are these samples free?

A: Yes, we provide 5-10 pcs connector free samples for testing. But you have to pay the shipping cost

4. Q: What about your delivery time?

A: Stock goods are delivered within 1 day; customized goods are delivered within 5-7days

5. Q: How to ship my order?

A: For small packages, send them by Express, such as DHL, FedEx, UPS, TNT, EMS. That's Door-to-Door service. For big packages, can send them by Air or by sea. We use standard export cartons. We will be responsible for any product damage caused during delivery.

6. Q: What kind of payment do you accept? Can I pay RMB?

A: Weaccept T/T(Wire transfer), Western Union, and PayPal. Please be sure that we can receive the same amount as the Invoice. And you can pay money In RMB. No problem.

7. Q: How about your company quality control

A: Strictly follow ISO9001. IQC, OQC, and IPQC QA occupy10% of our Quality department. The CCD test is applied to 99% of our company's product applications.

8. Q: I need your price list of all your products. Do you have a price list?

A: We do not have a price list of all of our products. Because we have so many items, it's impossible to mark all of their prices on a list, and the prices are always changing because of the material cost and quantity. And you can give us a list for all of the item you need, we will confirm carefully one by one,and give youspecification and price list

9. Q: Can you make customized products and customized packing?

A: Yes. We have made a lot of customized products for our customers before (mainly wire harnesses). About customized packing, there is no problem; we can put your Logo orother information on the packing. Just have to point out that it will cause some additional cost.

10. Q: What certificates do you have?

A: CE, CQC, UL, ISO9001, ISO14001, IATF16949, ISO45001, QC080000, etc.
