1.0mm 10Pins PCB Pin Header Connector SMT Type Double Row

Replace GCT BC032-10-A-2-0200-0200-L-B

Product Description

The 1.0mm 10-Pin PCB Pin Header Connector is a compact double-row, surface-mount (SMT) male header designed for PCB-to-PCB and board-level interconnection where PCB space is limited.

With a 1.0mm pitch and 10 contacts arranged in two rows, this pin header provides a compact contact arrangement for space-constrained electronic assemblies while remaining suitable for automated SMT production.

Compared with conventional 2.54mm or 2.00mm pin headers, the 1.0mm pitch format is more suitable for compact PCB layouts and higher contact density. Industry-standard 1.0mm dual-row SMT headers are commonly available in multiple pin counts and configurations, confirming this format as an established solution for compact PCB interconnection.

Why Choose a 1.0mm Double-Row SMT Pin Header?

1. Space-Efficient PCB Interconnection

The 1.0mm pitch provides a substantially tighter contact arrangement than traditional 2.54mm headers.

This makes the connector suitable for:

• Compact control boards
• Embedded electronics
• Portable electronic devices
• High-density PCB assemblies
• Mezzanine-style board connections

The market already offers 1.0mm dual-row SMT headers in configurations such as 10, 12, 14, 16 and 20 positions, demonstrating the suitability of this pitch for compact PCB applications.

2. Dual-Row Design for Higher Contact Density

The 2 × 5 contact arrangement allows 10 electrical contacts to be integrated into a compact connector footprint.

For engineers, this can help simplify PCB interconnection where board space is restricted without moving to a larger conventional pitch.

3. SMT-Compatible for Automated Assembly

The surface-mount structure is intended for PCB SMT assembly and reflow soldering, making the product suitable for automated electronics manufacturing.

For purchasing teams, this is important when evaluating:

• SMT line compatibility
• Pick-and-place assembly
• Reflow soldering
• High-volume PCB production
• Automated manufacturing processes

Comparable 1.0mm SMT pin headers are commercially offered specifically as surface-mount components for automated PCB assembly.

4. Suitable for Compact Electronic Designs

The 1.0mm pitch makes this product particularly relevant when a conventional 2.54mm or 2.00mm header occupies too much PCB area.

It can be considered when the design priority is:

compact footprint + multiple contacts + SMT assembly + PCB-to-PCB interconnection.
