2.54mm Double Row 2x20 Pin PCB Female Header

2.54mm double row female header connector

2x20 pin PCB female header

female header connector with 2.54mm pitch

Place of Origin:

China

Brand Name:

XTKCONN

Certification:

CE,SGS,ROHS,ISO9001

Model Number:

female header

Request A Quote

Product Details

Termination Style:

Solder

Package:

Tape Wrapping

Temperature Range:

-40 To 85 Degrees Celsius

Material:

Plastic

Durability:

High

Contact Pin Material:

Phosphor Bronze

Current Rating:

Connection Type:

Snap-On

Highlight:

2.54mm double row female header connector

2x20 pin PCB female header

female header connector with 2.54mm pitch

Payment & Shipping Terms

Minimum Order Quantity

1000pcs

Price

Negotiable Price

Packaging Details

Inner Package:in Reel; Outer Package: Reel In Carton

Delivery Time

5-7 Days

Payment Terms

L/C,T/T,Payyal

Supply Ability

3KK Pcs

1.27mm Pitch Female Header two row SMT Type with Peg 8-20P customized height and length of leg

Get Best Price

2.54mm Double Row 2x20 Pin PCB Female Header

Get Best Price

2.0mm Pitch Double Row Female Header Vertical Socket

Get Best Price

Customized 2.54mm Pitch Female Headers, Two-Row for Industrial Automation Control System

Get Best Price

86 13711847246

tinaliao@xtkconnector.com

86-769-85150486

Contact Now

Product Description

2.54mm Double Row 2x20 Pin PCB Female Header

Product Description

Parameter	Specification
Product Type	Double Row PCB Female Header
Connector Type	Female Header / Female Pin Header
Configuration	2 × 20 Positions
Total Positions	40 Pins
Number of Rows	2
Pitch	2.54mm / 0.100 inch
Mounting	PCB Mount
Orientation	Straight / Vertical; customized options available
Contact Type	Female Socket Contact
Mating Interface	2.54mm Male Pin Header
Contact Material	Brass or Phosphor Bronze, depending on configuration
Contact Plating	Tin or Gold Plating options
Insulator Material	Engineering Thermoplastic; material can be specified according to application
Insulator Color	Black is commonly available
Termination	Through-Hole / SMT options depending on configuration
Contact Resistance	Available according to selected contact/plating specification
Rated Current	Application-dependent; confirm against selected configuration
Rated Voltage	Application-dependent; confirm against selected configuration
Operating Temperature	Configuration-dependent
Flammability	UL94-rated material options available
Compliance	RoHS / REACH options available upon request
Customization	Pin count, housing height, plating, termination and other dimensions

Engineering Advantages

Name: 2.54mm Double Row 2x20 Pin PCB Female Header
Brand: Shenzhen Xietaikang Precision Electronic Co., Ltd.
SKU: female header
Price: 4.10 USD
Availability: InStock

Standard 2.54mm Interface

The 2.54mm pitch provides compatibility with a broad range of standard male pin headers and PCB interfaces.

This makes the connector practical for:

PCB-to-PCB connection
Board stacking
Wire-to-board connection
Development boards
Control modules
Test and programming interfaces

Flexible Configuration for OEM Projects

For volume OEM and ODM projects, female headers are commonly customized according to the actual PCB design.

Available engineering variables can include:

Pin count
Number of rows
Housing height
Contact length
Contact material
Contact plating
Mounting method
Insulator material
Insulator color

2.54mm Double Row 2x20 Pin PCB Female Header

Customization Options
Pin count: 2‑50 pins available besides standard 20P
Plating: gold flash / hard gold/matte tin
Feature: add polarizing key, locating pegs
Packaging: adjust reel dimension for your SMT feeder
Housing material upgrade for higher temperature requirements

Typical Applications

Industrial Control

Suitable for:

PLC control boards
Industrial controllers
Automation equipment
I/O modules
Control panels
Measurement equipment

The 2×20 configuration can provide multiple signal connections between a controller PCB and an expansion or interface board.

Embedded Systems

Typical applications include:

Embedded controller boards
Development platforms
Single-board computers
Microcontroller systems
Interface boards
Programming and debugging modules

The 2.54mm pitch is particularly common in development and embedded hardware because of its compatibility with conventional header systems.

Consumer Electronics

Potential applications include:

Audio equipment
Display control boards
Smart electronics
Interface modules
Home automation equipment

Robotics and Automation

The connector can be used for modular PCB connections in:

Robot controllers
Motor control boards
Sensor interface boards
I/O expansion modules
Machine-control systems

Factory Direct Customized 2.54mm Pitch Female Headers Fast Delivery for Industrial Automation Control System

Customizable Options Summary

Pin count: 2×2 up to 2×40 positions
Mounting: Through‑hole / SMT surface mount
Orientation: Straight vertical / Right‑angle
Housing height/stack height modification
Plating: Tin, selective gold, full gold plating
Polarization key / locating posts
Material upgrade to high‑temperature LCP / PA6T

Matching male pin header supporting

Our Service

Sample Availability & Policy

Samples are to be sent to our customers for free on their request, so long as they are willing to pay for the freight, or we can pay the freight for some old customers from our side as well, or the customer can pay the freight in advance, and we can ship samples with our courier as well.

Guarantees/Warranties/Terms and Conditions

We provide a product quality guarantee.
A 15-day quick delivery is assured.
Payment terms include T/T, but it is subject to negotiation, such as L/C, PayPal, Western Union, and more.

After Sales Service

Excellent service is offered through our network of offices and head office.
Please contact us by phone or e-mail, or if convenient, visit our office.
Aside from the friendly service, we offer the most competitive prices and flexible scheduling.

FAQ

Q: What's your MOQ?

A:Our MOQ usually comes to 1000 pcs, but we accept small order quantities for testing.

Q: Can I visit your factory?

A: Welcome to visit our factory, and we will show you our professional production process, and we can build long-term cooperation with you.

Q: What's your sample time? What's your delivery time?

A: 7 days for samples, and 15-20 days for mass production. It depends on the quantity.

Q : How do I inspect my goods?

A : You can inspect by visiting the factory, or ask a third party to inspect, or by picture inspection.

Q : How much does it cost to ship to my country?

A : The freight will be given by the freight company based on your Gross Weight and CBM.

Q:How do I know if you ship out my order?

A:The tracking number(DHL, UPS, FedEx, TNT, EMS, etc.), Air Waybill, or B/L by Sea will be sent to you as soon as your goods are shipped out. We also follow up on the delivery and keep you informed. The helpful after-service is provided. We support what you sell.

Q: Can I make personalized/customized products?

A: Sure, just send us your drawing or sample.
