2.54mm (0.1") Double Row Straight Male Pin Header – SMT Type (Vertical Surface-Mount), Gull-Wing Tails, Brass Square Pin, PA6T/LCP UL94 V-0, for High-Density PCB

Product Description

Overview

The 2.54mm Double Row Straight Male Pin Header – SMT Type​ is the surface-mount evolution of the classic 0.1" pin strip: brass square pins Ø0.64mm pressed into a black PA6T UL94 V-0 insulator, vertical 180° orientation with gull-wing SMD tails​ that reflow on the top side of the PCB — no through-holes, no wave solder. Supplied as breakaway dual-row stick (2×20 = 40-pin default for dev-board/GPIO; 2×40 for industrial controller), snappable every 2.54mm.

It is the mechanical/electrical clone of Konnra KR2542 dual-row SMT straight​ and Würth WR-PHD 610112249121, with optional positioning peg per Denentech P525-XXST02SM — but factory-direct priced and 5–7-day sampled.

Materials

• Insulator: PBT (Connfly DS1021, TXGA FPH254F1, CJT) black UL94 V-0; PA6T option (ICKEY 6T) for 260℃ lead-free wave; Nylon 6T/GWT 750℃ option

• Pin: Brass C2680 Ø0.64mm square (ICKEY CJT drawing confirms 0.64 SQ); phosphor bronze C5210 option for >500 cycle (Amphenol Quickie uses PB)

• Plating: Gold flash 0.05µm over 50µ" Ni on 5.84mm mate zone; matte tin 2–3µm on 3.0mm tail; selective 30µ" (0.76µm) gold​ option at 500pc MOQ (Connfly "全金 Type33" class)

• Plastic options: single-plastic 2.5mm height / double-plastic reinforced (anti-bend)

Application Industries

• IP Camera Modules​ – 2×20 straight header on sensor board-to-mainboard flex adapter, 2×5 on IR-LED driver sub-board

• DVR / NVR Mainboard​ – 2×40 dual-row backplane header for GPIO / alarm-in / RS485 / audio

• PoE Injector / Switch​ – 2×5 power+data header, gold-flash anti-oxidation in attic/wiring-closet

• Access Control Reader​ – 2×5 / 2×10 for Wiegand + LED + buzzer

• Smart Door Station / Video Intercom​ – 2×20 mezzanine to main MCU

• Traffic / ANPR Camera​ – 2×40 industrial backplane, wide-temp −40~+105℃

• Security Sensor Hub​ – PIR / smoke / glass-break aggregator board

Customization Options

• Count: 2×2 / 2×5 / 2×10 / 2×20​ / 2×40 (breakaway)

• Tail: 3.0mm (default) / 6.0mm (6T) / 10.8mm total (Connfly clone) / 8.5 / 11.96mm

• Plastic: single 2.5mm / double 4.3mm / 8.5mm tall

• Insulator: PBT+30%GF black (default) / PA6T / Nylon 6T / color

• Plating: gold flash / 30µ" selective​ / full tin / duplex

• Pin: brass (default) / phosphor bronze

• Orientation: straight/right-angle

• Packing: PE bag/tube/tray

Step Custom Process

1. Requirement Collection → 2. Technical Evaluation & Quotation → 3. 3D Drawing Review & Confirmation → 4. Mold / Tooling & Prototype → 5. Sample Test (contact R, retention, reflow) & Approval → 6. Mass Production → 7. Final QC & Shipment.
