2,0mm Pin Header for Servo Drive and Factory Automation Equipment

Product Description

The 2.0mm Dual-Row Straight Male Pin Header​ is the compact 0.079" grid interconnect chosen by servo drive makers and FA controller vendors​ when 2.54mm is too wide, but 1.27mm can't carry logic power. Brass square pins Ø0.50mm in black PBT+GF UL94 V-0 (or PA6T), 180° through-hole, gold-flashed over nickel on the mating zone. Supplied breakaway 2×5 / 2×10 / 2×20 – the counts on servo CN1 (encoder A/B/Z + I/O + COM), PLC 16DI/16DO daughtercards, EtherCAT slave I/O blocks.

It is the mechanical clone of KLS1-207B dual-row straight​ and 长江 A2005WRB 2.0mm dual-row​ – same 2.0mm grid, same Ø0.5 SQ pin, same 500V AC DWV – with factory-direct lead time.

Materials

• Insulator: PBT (Connfly DS1021, TXGA FPH254F1, CJT) black UL94 V-0; PA6T option (ICKEY 6T) for 260℃ lead-free wave; Nylon 6T/GWT 750℃ option

• Pin: Brass C2680 Ø0.64mm square (ICKEY CJT drawing confirms 0.64 SQ); phosphor bronze C5210 option for >500 cycle (Amphenol Quickie uses PB)

• Plating: Gold flash 0.05µm over 50µ" Ni on 5.84mm mate zone; matte tin 2–3µm on 3.0mm tail; selective 30µ" (0.76µm) gold​ option at 500pc MOQ (Connfly "全金 Type33" class)

• Plastic options: single-plastic 2.5mm height / double-plastic reinforced (anti-bend).

Application Industries

• Telecom switch backplane​ – 3×20 grouped (SIG/PWR/GND) for 1U ToR line card edge

• Data server riser/mezzanine​ – 3×10 for NVMe riser card to mainboard

• 5G DU/CU fronthaul card​ – 3×39 (117-pin) telemetry + sync + management bus (Kinghelm KH-2.54PH180-3X39P use case)

• Storage array controller​ – 3×40 triple-row for drive-backplane interposer

• Industrial DCS / VME64x adjacent​ – TE Eurocard DIN41612 96pos sibling for STE Bus / Futurebus+ (TE 650470-5 class)

• Optical transport / OTN​ – 3×5 power+control header on SFP28 line card daughter

Customization Options

• Count: 3×2 / 3×5 / 3×10 / 3×20​ / 3×39 / 3×40

• Spacer: 2.5mm insulator base (default) / + peg boss / 4.3mm double-plastic

• Tail: 3.0mm (default) / 6.0mm (6T) / 11.5mm total (Kinghelm L11.5 clone) / press-fit eye-of-needle

• Insulator: PBT V-0 black (default) / PA6T / Nylon 6T / color

• Plating: gold flash / 30µ" selective​ / full tin / duplex

• Pin: brass (default) / phosphor bronze

• Orientation: straight (default) / right-angle

Step Custom Process

1. Requirement Collection → 2. Technical Evaluation & Quotation → 3. 3D Drawing Review & Confirmation → 4. Mold / Tooling & Prototype → 5. Sample Test (contact R, retention, reflow) & Approval → 6. Mass Production → 7. Final QC & Shipment.
