12 Pin SMT Shrouded Header Connector 2.54mm Double Row

12 Pin SMT Shrouded Header Connector 2.54mm Double Row
12 Pin SMT Shrouded Header Connector 2.54mm Double Row

Large Image :  12 Pin SMT Shrouded Header Connector 2.54mm Double Row

Product Details:
Place of Origin: Guangdong,China
Brand Name: XTK
Certification: CE/ROHS
Model Number: Eector header
Payment & Shipping Terms:
Minimum Order Quantity: 500pcs
Packaging Details: inner package:in reel; Outer Package: reel in Carton
Delivery Time: 5-7 days
Payment Terms: L/C, T/T,Payyal
Supply Ability: 1KK pcs

12 Pin SMT Shrouded Header Connector 2.54mm Double Row

Description
Pitch: 1/1.27/2/2.54/3.96/5.08mm Materials: Contact: Brass Or Copper Alloy Insulator: LCP+30%G.F, UL94V-0 Rated
Type: Right Angle, Through Hole Mounting Number Of Contacts: 6-64 Pins
Contact Plating: Au Or S N Over 50µ Nickel Operation Temperature: -40 To +105°C
High Light:

SMT Shrouded Header Connector

,

12pin Shrouded Header Connector

,

Shrouded 12 pin header connector

2.54mm double row 12pin SMT box header connector ejector header






Ejector header connector is one of many connector types. It is not only a European type connector, but also a variety of connector classified according to the actual use. Because its shape is similar to horns, it is called ejector header connector. Ejector header connector is a very simple internal wiring equipment.



Description

Name Shrouded Header Connector
Pitch 2.54mm
Type SMT type
Insulator Color Black
Insulator Flammability UL 94V-0
Current Rating 2A
Contact Resistance(max) 30m ohm Max
Operating Voltage 60V AC/DC
Insulation Resistance(min) 1000M ohm Min at DC 500V
Contact materials Gold/Tin plating
Contact Plated Tin or gold over nickel
Insulator material PA6T
Processing Temperature -40~105℃
Packing Tray Packing
OEM/ODM Accepted



12 Pin SMT Shrouded Header Connector 2.54mm Double Row 0

Product name: Shrouded Header Connector
1. Product features: high temperature resistant to high voltage electrical conductivity
2. Product material: PA9T/LCP/PBT, plating surface treatment: gold-plated or tin plating
3. Scope of application: Mainly suitable for data communication and electronic equipment and welding on the PCB board, connected to the corresponding specification of IDC ribbon cable and the other circuit designers need to circuit. And if current usually transmission control signal





How to use Shrouded header connector?

Ejector header connector usually needs to pay attention to the insertion direction, perpendicular to the insertion direction and inclination.
1. Insertion direction: when the connector is fully inserted to u = 14.2, the specified contact resistance shall be ensured.
2. Perpendicular to the insertion direction: if the printed board or fixed board mounted connector is floating mounted, the design of free and fixed board mounted connector shall provide at least 1mm adjustable displacement.
3. Inclination: the design of free and fixed plate mounted connectors allows inclination error, which is ± 4 ° in longitudinal direction and ± 4 ° in transverse direction.
