19‑Pin 3‑in‑1 Micro SD / UHS‑II / UFS Card Connector | SMT 1.6 mm Height | Stainless‑Steel Shell

Highlight

✅ 19‑pin 3‑in‑1 combo socket: supports UFS / UHS‑II Micro SD / backward‑compatible UHS‑I Micro SD in a single footprint

✅ Ultra‑low 1.6 mm stacking height SMT surface‑mount design for slim device enclosure

✅ Stainless‑steel shield shell for EMI suppression & mechanical anti‑deformation

✅ Gold‑nickel plated contacts, stable high‑speed signal integrity for UHS‑II up to 312 MB/s

✅ Built‑in PCB retention claws, anti‑floating during reflow soldering

✅ RoHS, Low‑Halogen compliant; tape‑on‑reel packing for high‑volume SMT production

✅ Push‑push ejection mechanism with integrated card‑detect switch

Technical Specifications

General Mechanical Parameters

Material & Electrical Characteristics

Environmental & Soldering Guidelines

Product Features

• All‑in‑one 19‑pin design: accepts UFS card, UHS‑II Micro SD, backward compatible with UHS‑I Micro SD
• Push‑push ejection operation: one‑push lock / one‑push eject, no hinge cover
• SMT surface‑mount termination; built‑in dual retention claws to prevent component offset in reflow
• Slim 1.6 mm total stacking height, optimized for thin‑profile product casing
• Stainless‑steel shielding shell: EMI shielding, anti‑twist & anti‑drop mechanical protection
• High‑temperature LCP UL94V‑0 housing, matches standard JEDEC reflow profile
• Copper‑alloy contact beam with gold‑nickel mating plating; tin‑plated SMT terminals for good solderability
• Hardware card‑detect switch included for card‑present detection signal
• Embossed tape‑and‑reel packing for automated SMT assembly lines

Product Advantages

1. Single‑socket multi‑standard support: Replace two discrete sockets (UFS + Micro SD), shrink PCB footprint, lower BOM cost & layout workload.
2. 1.6 mm ultra‑low profile: Fits slim portable devices where height clearance is strictly limited.
3. Built‑in EMI stainless‑steel shell: Suppresses high‑speed signal interference, improves UHS‑II signal integrity for high‑speed read‑write.
4. Reliable SMT manufacturability: Retention claws prevent floating/offset during reflow; reel packing compatible with high‑speed pick‑and‑place.
5. Hardware card‑detect switch: Provides real‑time insertion/removal signal, reduces host‑side polling power consumption & firmware complexity.
6. Wide industrial temperature range ‑40~+85℃: Suitable for consumer and outdoor/industrial embedded projects.
7. Backward compatibility: Works with legacy UHS‑I Micro SD cards, avoids inventory compatibility risk for end‑products.
