Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin

Certification
China Shenzhen Xietaikang Precision Electronic Co., Ltd. certification
China Shenzhen Xietaikang Precision Electronic Co., Ltd. certification
I'm Online Chat Now

Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin

Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin
Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin
Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin

Large Image :  Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin

Product Details:
Place of Origin: Guangdong,China
Brand Name: XTKCONN
Certification: CE,SGS,ROHS,ISO9001
Model Number: DIN41612
Payment & Shipping Terms:
Minimum Order Quantity: 500pcs
Price: Negotiable price
Packaging Details: inner package:in tray; Outer Package: reel in Carton
Delivery Time: 5-7 days
Payment Terms: L/C, T/T,Payyal
Supply Ability: 1KK pcs

Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin

Description
Pitch: 2.54mm Insulator Material: PBT
OEM/ODM: Accepted Mounting Type: Right Angle
Operating Voltage: 60V AC/DC Termination: Solder
High Light:

Din41612 Shrouded Header Connector

,

2.54mm Shrouded Header Connector

,

Din41612 2.54 mm header connector

Right Angle Din41612 Pcb Connector 32 Pin Male 2.54mm Pitch 2 Rows 2*16 Pin





Product Name: DIN 41612 connector

1. the characteristics: the product precision and reliable performance, good force strong

2. material: 1 material: rubber core PBT plus 30% glass, terminal material: copper alloy.

Din41612 connector
Specification
Features:
* conforming to DIN 41612 and IEC 603-2 specifications.
* Available up to 3 rows and 96 positions with Solder,Press-fit and pin-in Paste terminations.
* Commonly used to carry audio and video signals.
* High Quality with 30 days 100% Money back.

Main Application:
* Switching/Routing,Enterprise,Transmission
* Home Entertainment,White Goods,Phones
* Servers,Personal Computing,Peripheral Device
* Technology,Lighting,Process Control
* Transportation,Instrumentation,Vehicle Electronics,Energy Transmission/Distribution Control
Electrical Characteristics
Current Rating at 20ºC
>1.5 Amp
Insulation Resistance
1000 MΩ min. at DC 500V
Contact Resistance
30mΩ max.at DC 500V
Dielectric Withstanding
1000V
Creepage and Clearance Distance
≥ 1.2mm
Mechanical characteristics
Mating Insertion Force per Contact
≤ 0.94N
Mating Extraction Force per Contact
≥ 0.15N
Contact Retention in Insulator
≥ 20N
Environmental and Processing
Operating Temperature
-55ºC to +125ºC
Material
Housing Material
PBT+30% Glass Fiber(UL94V-0)
Contact:Male-Brass
Female-Phosphor Bronze
Type
DIN 41612 B,C,Q,R,CD,RD TYPE
Company Advantages
* 15 years of experience in the connector industry
* Production capacity for each month: 300000000 pieces
* Quality and delivery guarantee
* Free sample
* Customization
* One-stop shopping for you



Right Angle Din41612 PCB 2.54mm Shrouded Header Connector Male 2*16 Pin 0



Scope of Application

It is widely used in displays, digital camera, MP3, MP4, PDA, computer, computer motherboard, a variety of mobile storage disk, card reader, security products, electricity meter, wireless telephone, mobile phone, interphone, program-controlled switches, VCD, DVD, LCM/LED display module, electronic toys, household appliances etc. As the most reliable connection plate to plate, wire to board provides.
