USB 3.1 Type-C 24-Pin Female Connector with Gold Plating, 5A Current Rating, and Socket for High-Speed Charging Connectivity

Product Highlights

✅ IPX7 IPX8 Waterproof Grade — Splash & temporary immersion protection for outdoor & portable devices

✅ USB 3.1 Gen2 | 10Gbps High-Speed Data

✅ Stable 5A, 100W PD Fast Charging — Consistent power output under continuous plug-unplug cycles

✅ PCB Mount Options: SMT / THR Through-Hole Reflow / Double-row SMT

✅ Anti-peel Reinforced Structure — Solves common pain points: pin lifting, cracking & PCB pad peeling from frequent mating

✅ Gold-Plated Contact Points — Low contact resistance & long cycle life

Technical Specifications

Compatibility & Cross Reference

Direct drop-in replacement for Molex, JST, Hirose Type‑C 24-pin connectors. Pinout & footprint fully matched, no PCB redesign required. Compatible with USB PD, QC, SCP fast charging protocols.

Product Features

• Reinforced anchor tabs to prevent PCB pad peeling after repeated plugging
• Precision molded housing, stable positioning during assembly
• Thick gold plating, anti-oxidation & anti-corrosion
• High-temp housing supports reflow soldering
• 24Pin full pinout for full USB3.1 signal & power path

Product Advantage

• Engineered to fix the industry pain point: long-term plugging causes pin detachment & board peeling
• Multiple mounting options fit different PCB layout designs
• IPX7 waterproof for harsh application scenarios
• Stable power delivery without voltage drop under 5A continuous load
• Strict signal impedance control for reliable 10Gbps high-speed transmission

Application

Outdoor power banks,

rugged handheld devices,

portable instruments,

smart wearables,

docking stations,

industrial handheld terminals,

small home appliances,

camera accessories.

Packaging

Tape & Reel packaging — Directly compatible with SMT automatic placement machines, ready for your assembly line.

Lead Time & Sample Policy

• Samples: 3 working days
• Mass production: 1–3 weeks
• MOQ: Negotiable
• ✅ Free samples available, fast sample delivery

Selection Guide for Engineers

1. Confirm gender: Male / Female
2. Confirm PCB mounting style: SMT / THR / Double-row SMT
3. Confirm waterproof requirement: IPX7 / non-waterproof
4. Confirm power requirement: ≤100W PD
5. Confirm PCB thickness & keepout space before footprint locking
6. For high plug cycle scenarios, select reinforced anti-peel version

Custom Service

Custom pin assignment, waterproof structure modification, housing surface treatment, customized logo, special plating requirements.
