USB Type C Connector 14Pin Female

USB Type C Connector 14Pin Female | Stainless Steel PCB Mount

3A Rated | ISO9001 Certified | SMT / THR Mid-Through / Double Row SMT Available

Product Highlights

• Waterproof Grade: Optional IPX7 / IPX8 waterproof structure
• Protocol Support: USB2.0 / USB3.0 / USB4.0 compatible
• Power Delivery: Stable PD fast charging up to 100W~240W
• Mount Options: SMT / THR Mid-Through / Double Row SMT
• Anti-fatigue Design: Reinforced soldering terminal, effectively prevent PCB pad peeling & pin fracture under frequent plug/unplug

Technical Specifications Table

Cross Reference & Replacement

Direct drop-in replacement for Molex, JST, Hirose equivalent 14Pin Type-C female receptacles. Pinout footprint compatible, no extra PCB redesign required. Custom pin mapping available.

Product Features

1. Stainless steel shell for high structural rigidity & anti-corrosion
2. Reinforced terminal anchor design to solve pad peeling risk from repeated plugging
3. Multiple mounting options for single-side / double-side PCB layout
4. High temp LCP housing, compatible with standard SMT reflow
5. Waterproof version optional for wet & outdoor devices

Product Advantage

• Solve engineer pain point: Long time plugging → pin break / PCB pad delamination
• Stable high-power PD charging up to 240W, no power drop under continuous load
• Consistent impedance for high-speed signal transmission
• Standard reel packaging, ready for automatic SMT placement machine
• Strict 100% electrical inspection before shipment

Application

Smart wearables,

handheld instruments,

industrial control modules,

portable power banks,

medical devices,

IoT sensors,

outdoor communication equipment,

small consumer electronics.

Packaging

Standard: Tape & Reel (Reel packing), ready for automatic pick-and-place SMT machine, direct loading on your production line. Tray packing available as an optional request.

Lead Time & Sample Policy

• Sample: 3 working days
• Bulk order: 1–3 weeks, depending on quantity & customization
• MOQ: Low MOQ for standard models
• Free samples available, fast sample release for engineering validation

Selection Guide for Engineers

1. Confirm mounting type: SMT / THR Mid-Through / Double Row SMT
2. Confirm waterproof requirement: Standard / IPX7 / IPX8
3. Confirm power requirement: 3A standard or 100W/240W PD high-power version
4. Confirm PCB thickness & pad space before layout
5. For heavy plugging scenario: Recommend reinforced anti-peel version

Custom Service

Certifications: ISO9001, RoHS, REACH, UL file available. Custom service:

• Adjust gold plating thickness
• High current upgrade (3A/5A)
• IPX7 / IPX8 waterproof modified version
• Custom pin length, shell shape, stacking version
• Provide drawings, 3D STEP, test report, PPAP file for industrial/medical projects

Custom pin assignment, waterproof structure modification, housing surface treatment, customized logo, special plating requirements.

About us & Manufacturing Capability

We are a professional precision connector manufacturer focusing on USB, FPC, BTB, Type-C, and high-speed interconnect components.

• Workshop: Dust-free ESD workshop
• Equipment: Automatic stamping, injection molding, high-speed plating, automatic assembly, 2D/3D inspection, impedance tester, life cycle tester
• Certificates: ISO9001 quality management system, RoHS, REACH compliant
• Support full verification: Plug life test, waterproof test, thermal cycling, solderability test

Quality Guarantee
Rigorous production and quality checks in each section, providing 6 6-year warranty for all our Female Connectors.

Responding within 24 hours
All inquiries will be replied to within 24 hours on working days.

Why Choose Us?

1)  Provide the perfect after-sales service for all our clients

2) Well-trained and experienced staff to answer all your inquiries in fluent English.

3) OEM and ODM: For any of your customized female connectors, we can help you design and put them into production

4) Distributor ships are offered for your unique design and some of our current models

5) Protection of your sales area, ideas of design, and all your private information

FAQ

Q1: Does this Type-C connector support 40Gbps data transmission?

A: The connector structure supports USB4/high-speed Type-C applications up to 40Gbps when matched with compatible controllers, cables, and system designs.

Q2: Is this connector waterproof?

A: Yes. This series uses a sealed waterproof structure. The final IP rating depends on the specific sealing design and customer requirements.

Q3: What is the current rating of this USB Type-C connector?

A: The connector supports up to a 5A current rating for VBUS applications, depending on the selected specification.

Q4: Can this connector be customized?

A: Yes. Customization options include:

• Waterproof structure
• PCB mounting design
• Contact plating thickness
• Shell design
• Mechanical dimensions

Q5: What industries commonly use this connector?

A: Typical applications include:

• Industrial electronics
• AI edge devices
• Automotive electronics
• Outdoor IoT equipment
• Smart terminals
• High-speed computing peripherals
