5 pin Micro USB Connectors Charging Port 5.65mm For Huawei ZTE

5 pin Micro USB Connectors Charging Port 5.65mm For Huawei ZTE

5.65mm Micro USB Connectors

ZTE Micro USB Connectors

5.65mm 5 pin charging port

Place of Origin:

Guangdong,China

Brand Name:

XTKCONN

Certification:

CE,SGS,ROHS,ISO9001

Model Number:

MICRO USB

Contact Us
Request A Quote
5 pin Micro USB Connectors Charging Port 5.65mm For Huawei ZTE
5 pin Micro USB Connectors Charging Port 5.65mm For Huawei ZTE 5 pin Micro USB Connectors Charging Port 5.65mm For Huawei ZTE
Product Details
Species:
Plug/socket
Characteristic:
Fire Resistance/flame Retardant
Working Frequency:
Low Frequency
Contact Material:
Copper
Number Of Cores:
Two/Five Cores
Shape:
Rectangle
Highlight:

5.65mm Micro USB Connectors

,

ZTE Micro USB Connectors

,

5.65mm 5 pin charging port

Payment & Shipping Terms
Minimum Order Quantity
2000pcs
Price
Negotiable price
Packaging Details
inner package:in reel; Outer Package: reel in Carton
Delivery Time
5-7 days
Payment Terms
L/C, T/T,Payyal
Supply Ability
3KK pcs
RELATED PRODUCTS
Good price LCP Micro Usb Female Connector Port 5 Pin 5.9mm Pitch With Edge online Video

LCP Micro Usb Female Connector Port 5 Pin 5.9mm Pitch With Edge

Get Best Price
Good price Plain Charging Port Female Micro USB Plug Socket 5P 5.9mm online Video

Plain Charging Port Female Micro USB Plug Socket 5P 5.9mm

Get Best Price
Good price Female 5 Pin 5.9mm Pitch Mini Micro USB Connectors With Post Plain Port online Video

Female 5 Pin 5.9mm Pitch Mini Micro USB Connectors With Post Plain Port

Get Best Price
Good price SMD Micro USB Connectors 5 Pin Charger Connector 6.9mm ISO9001 online Video

SMD Micro USB Connectors 5 Pin Charger Connector 6.9mm ISO9001

Get Best Price
Contact Us
86 13711847246
tina.liaoyan@foxmail.com
86-769-85150486
Contact Now
Product Description

5pin Common Micro USB Connector Charging Port For Huawei ZTE Huawei and other brand mobile,tablet GPS





Product Description



Specification: 5P
Type : Micro USB 5.65mm Curling edge column
Certification: ISO9001,ROHS and the latest REACH
Insertion Force: 0.5~2.0kgf
Removal Force: 0.8~2.0kgf
Durability: 10000 cycles
Current Rating: 3.0A
Voltage Rating: 5.0 V
Current Rating: 1.0A
Shield: 50mΩ /MAX
Insulation Resistance: 100mΩ/MIN
Operating Temprature: -25℃ - +85 ℃
Contacts: Copper Alloy
Housing: Thermoplastic , UL94 V-0

5 pin Micro USB Connectors Charging Port 5.65mm For Huawei ZTE 0



Drawing

5 pin Micro USB Connectors Charging Port 5.65mm For Huawei ZTE 1



Our Service



High quality
Passed the SGS authentication/ ROHS authentication etc....
The domestic long-term cooperative partner reached 5000, the trust level is high.

Shipment Items
Chanels
Express: DHL / UPS / TNT / FedEx / EMS / Aramex etc....
AirPost: Post-NL / Singapore Post / ePacket / CDEK /
Hongkong Post / DHL eCommerce / PTT etc....
Normal Post: China Post etc.

Diversified payments
Items:
Trade Assurance / Wire Transfer / MoneyGram
Western Union / PayPal / WeChat Pay / Ali Pay
Credit Card Chanels:
Trade Assurance / PayPal
Please send us the Remittance Copy when payments done.



FAQ



Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
