Double Layer 2×8 (16-Port) RJ45 Modular Jack with Dual LED, Metal Shield & Phosphor-Bronze Contacts – Stacked 8P8C Female PCB Through-Hole Connector for Gigabit Switch / Router / NIC
Product Description
|
Parameter
|
Specification
|
|
Connector Type
|
Modular Jack 8P8C (RJ45), Female
|
|
Configuration
|
2×8 stacked (double layer), 16 ports
|
|
Positions / Loaded
|
8 positions, 8 contacts per port
|
|
Mounting
|
Through-Hole, Right Angle (side entry 90°)
|
|
Pitch (TH pins)
|
2.54 mm row × 1.27 mm col (standard RJ45 PCB pattern)
|
|
Housing Material
|
Glass-filled PBT / PA46 / PA66, black, UL 94 V-0
|
|
Shield Material
|
Brass (copper alloy) 0.20–0.25 mm, Ni plated or Sn plated
|
|
Contact Material
|
Phosphor bronze Ø0.45–0.46 mm round / 0.35 mm flat
|
|
Contact Plating
|
Selective gold on mating (flash–50µ"), tin on tail
|
|
LED
|
Per port 2× (e.g. Green Link + Yellow ACT); optional colors
|
|
EMI
|
Shielded shell + top/side spring fingers + PCB ground tabs
|
|
Current Rating
|
1.5 A per contact
|
|
Voltage Rating
|
125 VAC RMS
|
|
Contact Resistance
|
≤ 30 mΩ
|
|
Insulation Resistance
|
≥ 500 MΩ @ 500 VDC
|
|
Dielectric Withstand
|
1000 VAC RMS, 60 s
|
|
Mating Force
|
≤ 2.2 kgf (8-contact plug)
|
|
Retention (plug-jack)
|
≥ 7.7 kgf
|
|
Durability
|
750 cycles (min)
|
|
Cat Rating
|
Cat5 / Cat5e / Cat6 (non-integrated magnetics version)
|
|
PoE Support
|
Yes (IEEE 802.3af/at/bt, when paired with external mag or PoE jack)
|
|
Operating Temp.
|
-40 °C to +85 °C (industrial -20~+70 option)
|
|
Compliant
|
FCC Part 68, IEC 60603, RoHS 2.0, REACH
|
|
Cross Ref.
|
TE 6368296-1 / 6116317-6; Connray 59BSE-2×8; Wayconn MJIB-88280XX; Pranelectronics JP-28-LED
|
|
Dimensions (ref)
|
L 28.2 × W 115.07 × H 25.30 mm (Wayconn class)
|
|
MOQ / Lead Time
|
500 pcs / 5–7 d sample, 3–4 w mass
|
The Double Layer 2×8 RJ45 Modular Jack integrates sixteen 8P8C female ports into one stacked ganged assembly: black UL94 V-0 PBT housing, brass shielding shell with EMI fingers, phosphor-bronze right-angle through-hole contacts, and a per-port dual-LED light-pipe array (Link + Activity). It is a non-magnetic (discrete) RJ45 jack — meaning no integrated transformer; you pair it with discrete magnetics or a PoE PHY front-end, which is exactly how TE 6368296-1 / Connray 59BSE / Wayconn MJIB-88280XX are specified.
The 2×8 stacked form factor is the workhorse faceplate block for 16-port and 48-port (3× 2×8) Gigabit switches, saving board length versus linear 1×8 ganging and keeping pick-and-place to a single component.
Application
Ethernet switches – 16-port Gigabit access switch (1× 2×8), 48-port ToR (3× 2×8 + 4× SFP+)
Routers/gateways – 16 LAN ports SMB router, xDSL/cable CPE
Network NIC / PCIe card – quad/16-port 1G monitoring NIC
Industrial DIN-rail switch – 16-port unmanaged switch for factory floor (wide-temp build)
PoE midspan/injector panel – paired with discrete PoE magnetics, 802.3at/bt
ATM / POS / vending – multi-port wired backhaul
Test & measurement/protocol analyzer – 16-port tap chassis
Medical / lab Ethernet hub – shielded discrete jack avoids mag saturation in sensitive analog
Networking Product: NIC, Hub, SWITCH, Router, Bridge, Work,
Station: PC/SYSTEM, Printer, Server, NB, I-CABLE MODEM, XDSL APPLICATION, SET-TOP-BOX.
Our advantage
1. Professional connector manufacturer, a variety of styles to choose from; we are factory direct sales, not only quality assurance but also affordable.
2. We can provide free samples for you to test, and then purchase if appropriate.
3. If the product is not what you want, please contact us directly and provide the product specifications you need.
4. Large-scale production workshop, fast delivery, immediate delivery from the spot, no need to worry about delivery.
5. One-to-one after-sales service, please feel free to contact us if you have any questions.
Customization Options
LED: None / 1-LED / 2-LED (GY/GG/RG/RY)
Shield finish: Ni plated / Sn plated / Cu bare
Contact gold: Flash / 3µ" / 15µ" / 30µ" / 50µ"
Tail: TH solder 3.05 mm / 2.54 mm / press-fit
Magnetics: None (discrete) / with integrated 10/100 mag / Gigabit MagJack (PoE+)
Housing: PBT black (default) / PA46 / PA9T / custom color
Ground: PCB ground tabs only / + panel EMI gasket
Custom Process
Requirement Collection → 2. Technical Evaluation & Quotation → 3. 3D Drawing Review & Confirmation → 4. Mold / Tooling & Prototype → 5. Sample Test (SI/EMI/LED) & Approval → 6. Mass Production → 7. Final QC & Shipment
FAQ
Q: Are you a trading company or factory?
A: We are a factory with 15 years of connector manufacturing experience; almost all of our products are made by ourselves.
Q: When can I get a quotation?
A: After you confirm the products you need, we will offer you a quotation.
Q: Do you accept customization?
A: Yes, we can accept customization as long as it is within our business scope, but you need to provide us with your demand quantity.
