5 PIN DC-058-1.3mm DIP Brass Contact Nylon Housing DC Power Adapter Plug Female Jack

Product Description

Designed as a female DC power jack socket, the connector supports a secure connection between external DC power sources and internal PCB circuits. It is suitable for applications where PCB space optimization, assembly efficiency, and connector compatibility are key design considerations.

Key Features of 5 Pin DC-058 DC Power Jack

Feature	Description	Customer Value
Product Type	Female DC Power Jack / DC Barrel Jack	Provides standard DC power input interface for electronic products
Model	DC-058	Easy identification for product selection and replacement
Pin Configuration	5 Pin	Supports multi-contact PCB connection design
Inner Diameter	1.3mm	Suitable for compatible DC adapter plugs
Mounting Type	DIP / Through Hole PCB Mount	Compatible with traditional PCB assembly processes
Contact Material	Brass	Provides conductive contact structure for power connection
Housing Material	Nylon	Provides mechanical support and electrical insulation
Structure Design	Sunken Type	Helps reduce connector height and optimize device space
Connector Gender	Female Jack	Designed for external male DC adapter plug connection
Application	DC Power Input	Suitable for various electronic devices and embedded systems

Compact PCB Mount Design

The vertical DIP structure allows the DC power jack socket to be directly mounted onto the PCB, making it suitable for electronic products with limited installation space.

Compared with larger power connection solutions, PCB-mount DC power connectors are commonly selected for:

1>Compact product designs
2>Embedded electronic systems
3>Smart control devices
4>Portable equipment

Highlights

RCA Female Connector: Ideal for audio and video applications.
Brass Touch Head Material: Durable and reliable connection.
1A Current Rating: Suitable for low to medium power needs.
30V Voltage Rating: Safe for various electronic devices.
Right Angle PCB Mounting: Easy integration into printed circuit boards.

Female DC Power Socket Structure

Provides a reliable connection interface between external DC power adapters and internal electronic circuits.

Suitable for AI and Smart Hardware Applications

Designed for compact electronic systems including AI edge devices, smart monitoring equipment, embedded controllers, and IoT terminals.

PCB Connector Orientations

The term PCB Connector refers to a basic multipin connection system, typically in a rectangular layout. A mating pair of PCB Connectors will either be board-to-board or cable-to-board (wire-to-board). The board-to-board layouts can give a range of PCB connection orientations, all based on 90-degree increments: Parallel or mezzanine – both connectors are vertical orientation;90 Degrees, Right Angle, Motherboard to Daughterboard – one connector is vertical, one horizontal;180 Degrees, Coplanar, Edge-to-Edge – both connectors are horizontal orientation.
