Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus

Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus
Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus
Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus

Large Image :  Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus

Product Details:
Place of Origin: Guangdong,China
Brand Name: XTK
Certification: CE,SGS,ROHS,ISO9001
Model Number: USB TYPE C
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: Negotiable price
Packaging Details: vacuum package,boxes in carton
Delivery Time: 5-7 days
Payment Terms: L/C, T/T,Payyal
Supply Ability: 1KK pcs
Contact Now

Data And Charge Power USB C 2.0 Connector Fast Charge For Samsung Oppo One Plus

Description
Application: PCB & Charger Durability: 5000 Cycles Min
Insulation Resistance: >1000 MΩ/500V DC Withstand Voltage: 100V
Operating Temperature: 25 ~ +85 Insulation Material: Thermoplastic & UL94V-0
Highlight:

100V USB C 2.0 Connector

,

SGS USB C 2.0 Connector

,

Thermoplastic Type C Connectors

USB C 2.0 Connector For Data And Charge Power Support Fast Charge For Samsung Oppo One Plus





Specification

USB Connector
Specification
FEATURES:
* Reversible plug and cable orientation for better user experience;
* Smaller connector size saves space;
* Easy and Quick usage;
* High Quality with 30 days 100% Money back;
* From the OEM Original Factory, same quality with a much better price.
Electrical Characteristics
Voltage Rating
5V AC
Contact Rating
5.0A
Contact Resistance
40 milliohms max
Insulation Resistance
100 megohms
Withstanding Voltage
100V AC
Mechanical Characteristics
Mating Force
5N to 20N
Unmating Force
8N to 20N
Durability
10,000 mating cycles
Environmental Characteristics
Operational Temperature
-30°C~ + 85°C
Material
Housing
HighTemperature Polymer
UL94V-0
Shield
Stainless Steel
------
Contact
Copper Alloy
------
Company Advantages:
* 20 years of experience in the connector industry
* Production capacity for each month: 300000000 pieces
* Quality and delivery guarantee
* Free sample
* Customization
* One-stop shopping for you



Our Advantage



Industry and Trade Integration Company
The product is from the factory to consumers directly, there is no additional cost for consumers.



Strict Test Makes Product High Quality
Before leaving the factory, our product has to check and quality tested many times, to ensure the product is of good quality.


OEM/ODM Customized Product
Customize and different requirements are OK, our engineers and factory would offer products according to your need.



Stable and Reliable Product Offer Ability
Our company owns 2 factories and many production lines, whether your requirement is big orders or sample orders, we would deliver them at the first time.



FAQ



1. where is your factory?

We are located in Shenzhen, Guangdong.

2. How about your quality control?
All the products will be 100% checked before the shipment.

3. Do you provide a sample?
Of course, free samples with freight were collected.

4. What is the lead time?
It depends on quality, generally within 7-15 days after paying for the order.

5. What is the MOQ?
In general 100pcs, but small order can be accepted.

6. Quality problems?
If there is any quality problem or question, we could offer technical support or return service.
